Products Dosing pumps water treatment


Automatic disinfectant dosing system

Dosing pumps water treatment


DOS.ECO is the ideal dosing system for injecting any type of disinfectant (liquid chlorine, pH, active oxygen and other types).

The programmer for disinfectant injection is integrated inside an ABS IP65 cabinet, ensuring a perfect seal. The display is a digital type. PH.DOS allows disinfectant dosing from 1 to 999 ml.

Disinfectant injection is programmed each time the unit is commissioned and can, upon request and depending on the type of disinfectant, be programmed hourly.

The 2 l/h peristaltic pump is independent of the electronics, ensuring the longevity of the system even in case of leaks in the dosing chamber.

Compact and panel-mounted and easy to install, DOS.ECO is particularly suitable for tanks with U.V. systems that require low-dose injection of disinfectant.

PH.DOS is sold and shipped with a kit consisting of:

  • Electronic control panel;
  • Peristaltic pump;
  • Bottom filter and injection barrel;
  • 5 meters of suction/discharge hose;
  • Wall mounting kit and spare fuse kit;
  • Instruction manual.

Please note that all equipment is covered by a 2-year warranty, valid only with installation and initial commissioning carried out by a licensed professional.

Show more Hide
Request information

Technical characteristics

Panel height 250mm
Panel width 290mm
Panel depth 110mm
Display Red digital
Power supply voltage 230V
Power supply frequency 50Hz
Circuit protection Delayed fuses
Minimum operating temperature 0°C
Maximum operating temperature 50°C
Disinfectant injection from 1 to 999ml from commissioning
Pump flow rate 2l/h
Pump counter pressure 1bar
Weight 2500g
Frame IP65
